Kramer VS-88HDxl Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
VS-88HDxl 8x8 3G SD/HD-SDI Matrix Switcher
RC-IR3 IR remote control transmitter

Step 2: Get to know your VS-88HDxl

# Feature
1 IR Receiver
2 POWER LED
3 ALL Button
4 OFF Button
5 IN SELECT Buttons
6 OUT SELECT Buttons
7 STO (STORE) Button
8 RCL (RECALL) Button
9 LOCK Button
10 TAKE Button
11 7-segment INPUT Display
12 GENLOCK BNC Connector
13 TERM HI-Z/75Ω Pushbutton
14 LOOP BNC Connector
15 INPUT BNC Connectors
16 RS-232 9-pin D-sub (F) Port
VS-88HDxl Quick Start
VS-88HDxl Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/VS-88HDxl
upgrades are available.
Function
Receives signals from the IR remote control transmitter. Lights yellow when receiving
signals.
Lights when the unit is ON.
Press ALL and then press an IN button to connect the selected input to all outputs.
Press OFF + OUT to disconnect the selected output from the inputs.
Press OFF + ALL to disconnect all outputs.
Press and hold OFF to toggle between dual link and normal mode.
Press to select the input to switch to the output.
Press and hold buttons IN1 to IN5 to change the genlock timing (see Step 4)
Press to select the output to which the input is switched.
Press STO and then press an IN/OUT SELECT key to store the current setting.
Press RCL and the relevant IN/OUT SELECT key to recall a setup from the non-volatile
memory.
Press and hold for three seconds to disable/enable the front panel buttons.
Press to confirm a command in Confirm mode (see Step 6).
Displays each input under the output number that it is switched to.
Connect to the genlock source.
Press to terminate the genlock source (75Ω) or release for looping.
Connect to the genlock connector of the next unit in the line.
Connect to the serial digital video sources.
Connect to a PC or a control device.
VS-88HDxl for the first time.
to download the latest user manual and check if firmware
1 Set of rack ears
1 Power cord
P/N: 2 9 0 0 - 3 0 1 2 5 6 QS
4 Rubber feet
1 Quick start guide
Rev: 2
