GENERAL INFORMATION
2005 SPORTSMAN 800 EFI
MODEL: . . . . . . . . . .
MODEL NUMBER: . A05MH76AU/AW
ENGINE MODEL: . . EH076OLE
Engine
Platform
Engine Model Number
Engine Displacement
Number of Cylinders
Bore & Stroke (mm)
Compression Ratio
Compression Pressure
Engine Idle Speed
Engine Max Operating Rpm
Cooling System / Capacity
Overheat Warning
Lubrication
Oil Requirements / Capacity
Exhaust System
Fuel System
Fuel System
Fuel Pump
(in tank assembly)
Fuel Filter(s)
Fuel Injector(s)
EFI Controller
Fuel Capacity / Requirement
Electrical
Alternator Output
Lights : Pod
Grill
Brake
Tail
Ignition System
Operating RPM
Ignition Timing
Spark plug / Gap
Battery / Model / Amp Hr
Circuit Breakers
Starting
Instrument Cluster
Polaris Twin Cylinder
EH0760LE011
760cc
2
80 x 68 mm
10:1
150- -200 psi
1150 ± 100 RPM
6500 Rpm ± 200 Rpm
Liquid - - 3.2 qt / 3 ltr
HOT on Instrument Cluster
Pressurized Wet Sump
Polaris 0W- -40 2 qt. / 1.9 ltr
Dual Pipe / Silencer
Electronic Fuel Injection (EFI)
25L per hour at 39 PSI
30 Micron in Tank
(not replaceable)
10 Micron In Line
(replaceable)
Bosch
Bosch MSE 1.1 ECU
4.13 gal US / 15.6 ltr
87 Octane (minimum)
89 Oxygenated
500 w @ 6000 RPM
50 watts
Two x 27 watts
8.26 watts
26.9 watts
DC/CDI Ignition
6000 RPM
13° BTDC @ 1200 RPM
RC7YC/ .035 in. / 0.9 mm
Lead Acid / 30 Amp Hr
Fan 20 amp - - Harness 20 amp
Fuel pump/ECU 15 amp
Instrument Cluster / Voltage
Regulator 6 amp
Electric
LCD
Drivetrain
Transmission Type
Transmission Capacity
Rear Gearcase Capacity
Front Gearcase Capacity
Gear Ratio : Low
Rev
High
Front Drive
Rear Drive
Clutch Type
Belt
Steering / Suspension
Front Suspension / Shock
Front Travel
Rear Suspension / Shock
Rear Travel
Ground Clearance
Shock Preload Adjustment
Front / Rear
Turning Radius
Toe Out
Wheels / Brakes
Wheel Size / Pattern - - Front
Wheel Size / Pattern - - Rear
Front Tire Size
Rear Tire Size
Recommended Air Pressure
F / R
Brake - - Front
Brake - - Rear
CLUTCH CHART
EBS Models have no helix/spring adjustment
Shift
Altitude
Weight
0--1800
20--60
Meters (0--6000)
(5631689)
(Feet)
20--58
1800--3700
(6000--12000) (5631216)
Drumshift - - H/L/N/Rev/Park
15 oz. / 450m
5 oz. / 150ml
5 oz. / 150ml
7.49:1
5.11:1
2.70:1
3.82:1
3.10:1
PVT w/EBS
3211106
A- -arm / MacPherson Strut
6.7 in. / 17.02 cm
Progressive Rate Independent
/Two x 2" Coil- -over Shock
9.5 in. / 24.13 cm
11.25 in. / 28.6 cm
Front - -Non Adjustable.
Rear - - Ratchet Style- - Std.
76 in. / 193 cm unloaded
0 - - 1/16 in / .0 - - .159 mm
Cast Alum. 26x8- -12 / 4- -156
(205/80R- -12)
Cast Alum. 26x11- -12 / 4- -156
(270/60R- -12)
26x8- -12
26x11- -12
5 psi Front
5 psi Rear
Dual Hydraulic Disc
Dual Hydraulic Disc
Driven Driven
Drive
Spring Helix
Spring
Blu/Green
3234234
3234233
(7041157)
Blu/Green
3234233 3234234
(7041157)
1.5
