Specifications - Icom ic-U80 Instruction Manual

D General
• Frequency coverage
• Mode
• Number of memory channels
• Usable temperature range
• Tuning steps
• Frequency stability
• Power supply
• Current drain
(at 7.2 V DC: typical)
Transmit at 4 W (High)
at 2 W (Mid)
at 0.5 W (Low)
Receive standby
power save
max. audio
• Antenna connector
• Dimensions
(projections not included)
• Weight
(approximately)
(without battery pack/case and ant.)
All stated specifications are subject to change without notice or obligation.
: 400.000–470.000 MHz
: FM, FM-N
: 207
(incl. 6 scan edges and 1 Call channel)
: –20°C to +60°C; –4°F to +140°F
: 5, 10, 12.5, 15, 20, 25, 30 and
50 kHz
: ±2.5 ppm
(–20°C to +60°C; –4°F to +140°F)
: Icom specified battery pack or
case
: 1.4 A
1.0 A
0.5 A
: 58 mA
32 mA
280 mA (internal speaker)
160 mA (external speaker)
: BNC (50 W)
: 58(W)×112(H)×30(D) mm;
9 13 3
2 ⁄ (W)×4 ⁄ (H)×1 ⁄ (D) in
32 32 16
: 140 g; 4.9 oz

SPECIFICATIONS

D Transmitter
• Modulation system : Variable reactance freq. modulation
• Output power : High 4 W, Mid 2 W, Low 0.5 W.
(at 7.2 V DC)
• Max. frequency deviation : FM
• Spurious emissions : Less than –65 dBc
• External mic. connector : 3-conductor 2.5 (d) mm (
D Receiver
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 46.35 MHz, 2nd: 450 kHz
• Sensitivity : 0.2 μV typ.
(at 12 dB SINAD)
• Squelch sensitivity : 0.11 μV typ.
(threshold)
• Selectivity : FM
• Spurious and image rejection : 70 dB typ.
• Intermodulation : 70 dB typ.
• Audio output power (at 10% distortion)
: 0.75 W typ. with a 16 Ω load
Internal speaker
: 0.4 W typ. with a 8 Ω load
External speaker
• External speaker connector : 3-conductor 3.5(d) mm; (
15
±5.0 kHz
(wide)
FM ±2.5 kHz
(narrow)
1 ⁄ ˝)/2.2 kΩ
10
70 dB typ.
(wide)
FM 60 dB typ.
(narrow)
˝)/8 Ω
1 ⁄
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
57
