6
Parking brake lock lever
Brake pedal
5314M-0602-010-E
Blade clutch lever
5317M-0604-030-E
Rotary height adjusting switch
5314M-0602-030-E
OFF
5313M-0604-020-E
Operation
3. Depress the brake pedal to firmly stop the
4. Lock the brake pedal, using the parking brake
5. Confirm that the blade clutch lever is
6. Push the "HIGH" side of the rotary height
7. Turn the main switch to "OFF" to stop the
ON
8. Pull out the key from the main switch.
Main switch
-36-
machine.
lock lever.
positioned at "OFF".
adjusting switch to raise the blades to the
highest position. (Check the position of the
rotary cutter through the blade height monitor.)
engine.
