Protocol Stack Page

Clicking the Protocol Stack link in the menu bar displays the Protocol Stack page. Here
you can configure lower level network stack-specific configuration settings.
Under Current State, there is a Clear link to remove all addresses and a Remove link to
remove the individual address shown. If you click Clear or Remove, a message asks
whether you are sure you want to perform the operation. Click OK to proceed or Cancel
to cancel the operation.
Protocol Stack Page
Settings
Send RSTs
Ack Limit
Send Data
IntelliBox-I/O 2100 User Guide

Figure 12-9 Protocol Stack Page (TCP)

Table 12-7 TCP Protocol Stack Page

Description
RST is a TCP control bit that informs the receiving TCP stack to
end a connection immediately. However, sending this bit may
pose a security risk. Select whether you want the RST control bit
sent to end a connection immediately. Choices are:
Enabled = the RST bit is sent. (default)
Disabled = the RST bit is not sent.
Specify a value indicating the number of packets which must be
received before an ACK is forced. If there is a large amount of
data to acknowledge, an ACK will be forced before this. If the
sender TCP implementation waits for an ACK before sending
more data even though the window is open, setting Ack Limit to
"1" packet will improve performance by forcing immediate
acknowledgements.
Determine when data may be sent to the network. Choices are:
Standard = waits for an ACK before sending a packet less than
the maximum length.
Expedited = sends data whenever the window allows it.
12: Advanced Settings
135
