L VM- 171W - 171WP
FRONT
POWER
ANALOG
SDI-A
SDI-B
DVI
SCAN
ASPECT
MARKER
[ANALOG] button/lamp
- Used when ANALOG INPUT is selected. Sub Menu for analog input menu-selection appears.
[SDI-A] button/lamp
- Used to select SDI-A Input
[SDI-B] button/lamp
- Used to select SDI-B Input
[DVI] button/lamp
- Used to select desired DVI Input. (DVI DIGITAL, DVI ANALOG, HDMI)
[SCAN] button/lamp
- Used when transferring from OVER SCAN mode to UNDER SCAN mode.
(Compatible up to SD 1:1 SCAN mode.)
[ASPECT] button/lamp
- Used to toggle aspect ratio in SD from standard to anamorphic.
[MARKER] button/lamp
- Used to toggle on Screen Marker on/off
The type of marker at work may be selectrd on the main menu
Name & Function of Each Part
TALLY L L
APERTURE
BRIGHT
CHROMA
CONTRAST
VOLUME
ENTER
UP/DOWN
MENU
WAVEFORM
PHASE
BLUE ONLY/MONO
H/V DELAY
