Product Specification - TVLogic LVM-171WP Operation Manual

L VM- 171WP
Input
Output
Input Signal
Analog Input Spec
SDI Input Signal
Formats
Audio In
Audio Out
LCD
Power
Power Consumption (Approx.)
Operating Temperature
Storage Temperature
Main Body Dimensions (mm/inch)
Main Body Dimensions (With Stand)
Weight
Accessory
Option
* Above specifications may be changed without notice
P

Product Specification

1 x DVI- I
3 x BNC
2 x BNC
1 x HDMI
3 x BNC
2 x BNC
Analog
HD-SDI
SD-SDI
DVI
HDMI
Composite
S -Video
Component
RGB
SMPTE-274M
SMPTE-296M
SMPTE-260M
SMPTE-125M
ITU-R BT.656
Size
Resolution
Pixel Pitch
Color
Viewing Angle
Luminance of white
Contrast
Display Area
DVI IN
Analog Input
SDI A/B Channel Input
HDMI Input
Analog Output
SDI A/B Channel (Active Through Out)
Composite / S-Video / Component / RGB
1.458Gpbs
270Mpbs
4VESA/IBM Modes
80i/480p/720p/1080i & VESA/IBM Modes
1.0Vpp (With Sync)
1.0Vpp (Y With Sync), 0.286Vpp(C)
1.0Vpp (Y With Sync), 0.7Vpp (Pb,Pr)
1.0Vpp (G With Sync), 0.7Vpp (B,R)
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
720p (60/59.94/50)
1035i (60/59.94)
480i (59.94)
576i (50)
Embedded Audio
Analog Stereo (Phone Jack)
Analog Stereo (Phone Jack)/Stereo speaker
16.84"
1366 x 768 (16:9)
0.273(H) x 0.273(V) mm
16.7M(true), 24bit
H : 178 degrees / V : 178 degrees
280cd/ (Center)
900:1
372.9 x 209.6 mm
DC 12V/ DC 24V / AC 100~240V (50~60Hz)
72 Watts(Max. 6A)
0°C to 40°C (32°F to 104°F)
-20°C to 60°C (- ( 4°F to 140°F)
427 x 310 x 90.5 (16.8 x 12.2 x 3.5)
474 x 327 x 150 (18.6 x 12.8 x 5.9)
7Kg / 15.4 Lb
AC Power cord, Manual
Carrying case, V-Mount, Hood, 19" Rack Mountable Kit, ND Filter
