L VM- 171W - 171WP
[H/V DELAY] button/lamp
- Used when checking horizontal sync and vertical sync simultaneously.
[BLUE ONLY] [MONO] button/lamp
- You may remove R(red) and G(green) from the input signal and play the screen only in
B(blue) signal. And if the button hit twice, it will turn to MONO mode. (This mode use
only luminance value.)
[PHASE] button
Used when changing the CHROMINCE, PHASE and Closed Caption values during menu in-activation.
- Chroma = > Phase >
- Chroma = > Closed Caption : SDI-A/B modes. >
- Chroma = > Phase : S-Video mode. >
- Phase(Auto Adjustment) : DVI-Analog mode.
- Chroma : Component mode.
[W-FORM] button/lamp
- Used to activate the Waveform or Vector Scope. Pressing the button once will activate the
Waveform, pressing the button twice activates the Vector Scope.
[MENU] button
- Used when OSD menu is activated.
[DOWN] button
- Used when moving within the menus during OSD menu activation.
[UP] button
- Used when moving within the menu during OSD menu activation.
[ENTER] button
- Used when confirming a chosen value (or mode) during OSD menu activation or inactivation.
[POWER] button/lamp
- Used when power on and off.
- It affords power supply, which may be indicated by indication lamp. The lamp is RED
during power supply and GREEN during system is in operation. In case of power cut and
sudden shut off of the power, our monitor keep previous setup stage.
[TALLY] lamp
- LED indicating monitors current status.
[APERTURE] knob
- Used to adjust the picture sharpness between MAX(5) and MIN(-1).
#Aperture is not available in DVI Analog mode.
Name & Function of Each Part
= > Closed Caption : Composite modes. >
