[1] ANALOG / DVI MODE USAGE
This product is capable of processing all input signals usable in ANALOG/DVI mode.
The ANALOG/DVI input settings are as follows:
1. Press ANALOG or DVI button on the front of the product and activate the menu below.
2. Highlight the value you desire by using the UP/DOWN button and press the MENU
button to confirm your selection. From this point the OSD menu operates identically
to the MENU operations discussed above.
Warning!!
When using ANALOG and DVI modes, always check the input method and modify the setting
as needed for optimized output results.
[2] HD/SD 1:1 SCAN MODE
Widescreen models provide not only an UNDERSCAN mode but also an SD 1:1
SCAN mode. These modes maybe selected as follows:
1. Transfer to UNDERSCAN by pressing the SCAN button on the front of the monitor.
2. Press the SCAN button again after the mode is shifted to UNDERSCAN mode to
transfer to HD/SD 1:1 SCAN mode.
3. Press the ENTER button to change the picture position in 1:1 SCAN mode.(1080i/1080p modes)

Other Functions

Analog DVI
