7.3.1.3 EIB controlled lighting

EIB lighting supports on/off and dimmer control. You must also specify whether the
EIB addressing is 2 or 3 level.
If you select thee dimmer function then it is also necessary to specify the dimmer
increment as a percentage of 100% e.g. If you choose 25% then each dim plus
command will increase the intensity by 25%.

7.3.2 Motorized element configuration

Webdynhome motorized elements are configured in the same manner as the lighting
elements see below.

7.3.2.1 X10 motorized elements

X10 controlled motorized elements are configured as shown below :
Page 38
Light name
Interface type
Module address
Option pulse
and timing in
seconds
Light name
Interface type
Module type
EIB group
addresses
Dimmer
increment
