Initial System Installation Procedures; Initial Contact With The Webdynhome - Webdyn home Installation Manual

6 Initial system installation procedures

Upon connection of the power supply the LAN LED should light immediately (if it
starts flashing don't worry, it is indicating LAN traffic activity).
The CPU LED should start flashing after 15 seconds. This indicates that the system
has successfully booted and has now entered the memory load phase. The length of
time taken by the memory load phase will vary based on the system configuration.
If these LED's don't behave as described above after the connection to a suitable
power supply then please contact your supplier.
These next steps will allow you to establish an initial connection with your
Webdynhome from a PC that is equipped with a standard Web browser such as
Internet Explorer™ or Netscape Navigator™.
During the development of the Webdynhome a specific style has been applied to the
user interface dedicated to the installation of the system :
Simple pages containing a minimum of elements
A screen definition of 800x600 (the use of a PDA is restricted to the user
screens)
Large buttons to improve readability
Please verify that your screen definition is adapted to standard Web browsing before
continuing.

6.1 Initial contact with the Webdynhome

In order to connect to the Webdynhome for the first time you need to make sure that
your PC is configured for access to the correct IP subnet.
IP subnet
Network subnet mask
192.168.1.XX
255.255.255.0
In order to verify whether your PC is configured
correctly, please follow the next steps
Open the Control Panel for your PC and select
the Network Connections option.
After selecting the Local Area Network you will
be presented with a dialog box looking
something like this :
Select the Internet Protocol (TCP/IP) item and
then click on the properties button.
Page 18
