5.1.3 Output characteristics:

R
82C55 output
The output relay is electromechanical and is open at rest.
It has the following characteristics :
- Voltage : 48Vcc max
- Current : 1A
Connector : Weidmüller 3.5mm with cable section 0.5-1.5mm².

5.1.4 RS232 COM1 Interface

Baud rate : 1200 to 115200 bauds - Connector : SubD 9pts Male.
Pinouts :
5.1.5

RS232 COM2 Interface

Baud rate : 1200 to 115200 bauds - Connector : SubD 9pts Male.
Pinouts :
REED relay
9
T 13
C
Pin Signal Description
1 CD
2 RX
3 TX
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9
Pin
2
3
5
7
8
Page 16
Webdyncast
output
VCC
7
6
1
Carrier detect
Receive
Transmit
Data Terminal Ready Output
Ground
Data Set Ready
Ready To Send
Clear To Send
Signal Description
RX Receive
TX Transmit
GND Ground
RTS Ready To Send
CTS Clear To Send
Line out
Line in
External interface
Direction
Input
Input
Output
Input
Output
Input
Not connected
