7 Environment equipment configuration

We are now going to start the real configuration of the
You must login to the system as the user "install" either via the login screen or via the
specific URL http://www.xxx.xxx.xxx.xxx/install
IP address of your Webdynhome.

7.1 Configuration overview

Each device or equipment that is to be controlled by the Webdynhome must be
configured on the system. Once configured, all of the menus relating to the control of
the equipment will be automatically generated for you.

7.2 Environment control

The Webdynhome has been designed to control a wide range of environment style
devices including but not limited to: lighting, motorised elements, inputs, switches,
relays etc. Let's look at the procedures necessary to configure the Webdynhome
relative to your environment.
Click on the Environment link and the following menu appears :
The "interface" selection specifies the exact device that must be connected to the
Webdynhome.
Webdynhome.
where xxx.xxx.xxx.xxx represents the
The menu Interfaces is used to
assign a generic environmental
device protocol to a specific
Webdynhome port.
You must specify a unique interface
name : Maximum 10 characters
There are currently 2 different
interface types to choose from, where
the "type" is used to select the
physical interface (RS232) and the
"port" is used to define the precise
port number.
Page 34
