Removing The Front Panel Seal - Electrolux Built-in Ovens Service Manual

2. Using a standard screwdriver, lever open the anchor tabs and release the lamp-holder
(see Fig. 12).
Fig. 12
1 - LAMP-HOLDER
2 - SCREWDRIVER
N.B.: The arrows indicate the
positions of the anchor
tabs
2.5 - REMOVING THE FRONT PANEL SEALING RING
In order to remove the front panel sealing ring, it is sufficient to detach the four anchor
elements from the relative holes, and pull the sealing ring outwards (see Fig. 13 and 14).
Fig. 13
ANCHOR POINTS FOR THE
FRONT PANEL SEALING
RING
SOI 04.04 FV 10/50 599 35 96-40
