A: Technical Specifications

Keyboard and Mouse

SCSI

192
Table A-3 (continued)
Pin Assignment
6 RECEIVE–
7 (Reserved)
8 (Reserved)
Table A-4 shows the cable pinout assignments for the keyboard and mouse ports.
Table A-4 Keyboard and Mouse Ports (6-pin MiniDIN) Pinout Assignments
Pin Assignment
1 KEYBOARD/MOUSE DATA
2 (Reserved)
3 GROUND
4 KEYBOARD/MOUSE POWER (+5V)
5 KEYBOARD/MOUSE CLOCK
6 (Reserved)
Table A-5 shows the cable pinout assignments for the SCSI port.
SCSI Port Pinout Assignments
Table A-5
Pin Assignment
1 GROUND
2 GROUND
3 GROUND
4 GROUND
Ethernet 10-Base T/100-Base T Port Pinout Assignments
Pin Assignment
35 -DB(12)
36 -DB(13)
37 -DB(14)
38 -DB(15)
007-4486-001
