VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide
7. If required, any previously programmed routes may be cleared by selecting the 'Clear-all' option. 7. If required, any previously programmed routes may be cleared by selecting the 'Clear-all' option.
Menu: Configuration System Router Ctrl Remote Unit address <n> Digital In Menu: Configuration System Router Ctrl Remote Unit address <n> Digital In
8. Any input that is not used should be configured as 'Not-Conf'.
Menu: Configuration System Router Ctrl Remote Unit address <n> Digital In
Reference to Configuration Tool (Remote I/O Unit Digital Input)
-
1
2
5
Is sue: 02 complete, approved
Page 88 of 166 Page 88 of 166
Contact#<nn> Routing Control Clear-all Contact#<nn> Routing Control Clear-all
Contact#<nn> Not-Conf
4
6
3
