VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide
Ref. Item
75 Inputs
76 Outputs
77 Ctrl
78 Misc
79 Noise
80 Mic/Line
81 DVA
82 Fallback
83 ANS
84 O/P #n - OUTPUT n
85 Contacts
86 Permanent
87 Remote
88 Sounder
-
VAR8 Menu Description
Access to Router input configuration functions.
Access to Router output configuration functions.
Access to Router contact and Remote I/O Unit (BMB01) configuration functions.
Access to Router general parameter configuration functions: RTR MISC MENU.
Access to Night Time Volume Control configuration functions.
Allows the microphone/line inputs to be configured as one of: Fire Microphone /
Zoned Fire Microphone / Paging Microphone / Single Button Microphone /
Network Channel / Miscellaneous Input or Unused.
Allows the Background Music and Mute inputs to be configured.
Allows the selection of one of the four available DVA messages. Once the
specific DVA has been selected, the following sub-menus are presented: 'Gain',
'Pri', 'Name', and 'Class'.
Enables a fallback local audio source to be defined for each Audio Control Unit
DVA and Music input, and for local inputs. The fallback audio source is used if
the original audio source is unavailable for any reason.
Default value: 'Not-Conf'
Enables the user to configure how the output gain is modified when the input is
routed to an output monitored by an ANS. The inputs may be from Slave Unit
(Local) or from the Audio Control Unit (Network).
Enables the user to scroll through the Router outputs for selection.
Where: nn=1 to 8
'OUTPUT nn' is the default name for a Mic/Line input. It may vary according to
the local configuration.
Allows the user to select a contact, and define its use as one of:
• Not-Conf
• Routing
• External Fault
Allows each output to have an input associated with it to which it is permanently
routed. Normally used to route background music at low priority to desired areas.
The outputs in question are the outputs of the Slave Units on the network. The
inputs may be either one of the Audio Control Unit audio sources (NETWORK
IP), or the Slave Unit (LOCAL IP) audio sources.
Permanent routes will cease to operate if power failure should occur and
the system has to run on battery backup. For this reason it is recommended
that permanent routes are only used for background music or other non-
safety critical operation.
Configures units on the RS485 bus. The user selects a remote unit by multi-drop
address, and defines the type as one of:
•
Not Configured
•
Expand I/O (also known as Remote I/O)
•
Fire loop interface unit
Enables user to suppress or enable the fault sounder during announcements
from the fire microphone.
Possible values: 'Enabled' or 'Suppressed'
Default value: Enabled
When VAR8 is networked, the fault sounder is automatically suppressed.
Is sue: 02 complete, approved
Page 135 of 166
Description/Possible Settings
