Stand-alone Operation Setup

The VAR8 is by default configured for 3-channel network operation mode. If its configuration is
cleared at anytime, it defaults to 3-channel network operation mode.
To Change the DAU from Network Mode to Stand-Alone Mode:
1. Set the RS232 port to be connected to a host PC.
Menu: Configuration System Misc Async-Port Connect to PC
2. Set the number of Network Audio Channels to 0.
Menu: Configuration System Network Channels
3. Disable the surveillance tone detection for Mic/Line inputs 1, 3, and 4.
Menu: Configuration System Router Inputs Mic/Line I/P #<nn> Audio Surv
4. Set Mic/Line inputs 1, 3, and 4 to Unused in order to exclude these inputs from routing and audio
monitoring. An 'Unused' input can then be normally used for the connection of microphones or other
audio sources.
Menu: Configuration System Router Inputs Mic/Line I/P #<nn>
-
