VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide
10.2

DVA Input Emergency Class Configuration

The Emergency Class is only relevant on networked units, and is used by the ACU to drive the red and
green LED of zone select buttons on the ACU's front panel and on Fire Microphones connected to the ACU
as follows:
−
The red LED is turned ON continuously if any output in the group configured for the button is connected
to an input that has been configured as a High Priority Emergency source.
The green LED is turned ON continuously.
−
The red LED flashes ON and OFF repeatedly if any output in the group configured for the button is
connected to an input that has been configured as a Low Priority Emergency source, and no output in
the group is connected to a High Priority Emergency source.
The green LED is turned ON continuously.
−
The red LED is turned OFF if any output in the group configured for the button is connected to an input
that has been configured as a Non Emergency Priority source, and no output in the group is connected
to a High or Low Priority Emergency source.
The green LED is turned ON continuously.
−
The red LED is turned OFF if all outputs in the group configured for the button are not connected to any
input.
The green LED is turned OFF.
This is used to indicate the emergency DVA message status of the zone group configured for a zone select
button on the ACU's front panel and Fire Microphones connected to the ACU, as described in
is achieved by setting the appropriate Emergency Class to each of the VAR Router inputs, as described in
the following procedure.
Table 6 Zone Select Button LED Indication (ACU and Fire Microphones Connected to an ACU)
LED
Green Red
OFF N.A.
ON
Flashing
ON
OFF
From ACU V1.5.0114 or later, it is possible to configure a microphone connected to an ACU
between the mode described above and the standard mode. In the standard mode the
Emergency Class does not affect the behaviour of the LEDs with the red LED turning ON
continuously to indicate that the zone (either one or more of the group of zones controlled by
this button) is already in use by another input, and the green LED indicating the zone selection
state. Please refer to the Audio Control Unit's Commissioning and Operation Guide for further
details.
-
Zone Select Button
No input is broadcasting to any output in the zone group controlled by this button.
EVACUATE message is playing to an output
ALERT message is playing to an output
N
o EVACUTE message is playing
button.
A Non Emergency audio source, e.g. microphone announcement or music, is broadcasting
in the zone group
to an output
N
o EVACUTE and no ALERT messages are playing
controlled by this button.
Is sue: 02 complete, approved
Indication
in the zone group
in the zone group
to any output in the zone group
controlled by this button.
Page 62 of 166
Table
controlled by this button.
controlled by this button.
controlled by this
to any output in the zone group
6. This
