ASL INTERCOM VAR8 Operation And Maintenance Manual page 131

VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide
Ref. Item
21 Routing
22 Contacts
23 ANS
24 Frame#nn -
25 System
26 Frame#nn
27 Commis
28 Desc
29 O/P Map
30 Temp
31 Slot#n
-
VAR8 Menu Description
This indicates what input is currently routed to each output.
For example:
OP1 OP2 OP3 OP4 OP5 OP6 OP7 OP8
L00 L04 N02 L00 L08 N07 L00 L00
Where:
L00 = Nothing currently routed to O/P 1
L04 = Local I/P 4 currently routed to O/P 2
N02 = Network I/P 2 currently routed to O/P 3
etc.
Enables the user to view the actual physical contact state (1=active, close,
0=inactive, open) on the Router and on a Remote I/O Unit.
Enables the user to enable the user to view the values read in dB by ANS
sensors in an output zone:
Cur = The current reading from the ANS sensor / the current attenuation level.
Act = The minimum / maximum readings from the ANS sensor, with an input
routed to the output. It measures the volume of an announcement.
Idle = The minimum / maximum readings from the ANS sensor, with nothing
routed to the output. It measures the genuine ambient noise.
Enables the user to scroll through the list of configured amplifier frames. When a
frame has been selected, the sub-menus are displayed.
Where: nn=1 to 63
Default value: Lowest numbered frame
Enables user to scroll through the system fault log (history of last 200 faults).
Scrolling through the fault log is performed using up/down keys or rotary
encoder.
Default value: The most recent record.
Enables the user to scroll through the list of configured amplifier frames. When a
frame has been selected, the user can scroll through the fault log (history of last
200 faults) maintained for the selected frame. Scrolling through the fault log is
performed using up/down keys or rotary encoder.
Where: nn=1 to 63
Default value: Lowest numbered frame
Displays the detected configuration of the frame (type and rating of amplifiers in
each of the four amplifier slots).
Enables the user to view/edit the frame description. For reference only.
Possible values: alphanumeric string of up to 12 characters
Default value: blank
Enables each slot to be associated with an output. This is so that faults can be
mapped from amplifiers to zones - specifically in relation to faults displayed by
fire panel interface units.
Enables the user to define a temperature alarm. A fault will or not be raised if the
configured temperature at the frame is exceeded.
Possible values: 'Not-Conf' or 'Config'd'
Max Temp(°C)= 15 to 99°C
Default values: 'Not-Conf' and 'Max Temp(°C)=70'
Enables the user to scroll through the slots in the selected frame.
Where: nn=1 to 4
Is sue: 02 complete, approved
Page 131 of 166
Description/Possible Settings
