Permanent Route Configuration

Permanent Route Configuration
To Program Permanent Routes: To Program Permanent Routes:
1. Access the following menu, and set-up the required permanent routes. 1. Access the following menu, and set-up the required permanent routes.
Menu: Configuration System Router Ctrl Permanent Menu: Configuration System Router Ctrl Permanent
2. Select the input that will be routed to an output.
The input may be either one of the Audio Control Unit (NETWORK IP) audio sources, or the Slave Unit
(LOCAL IP) audio sources.
Reference to Configuration Tool
-
Is sue: 02 complete, approved
Page 79 of 166 Page 79 of 166
