84 PERIODIC SERVICE
[RTV-X900]

Protected circuit

Fuse
Capacity (A)
No.
1 5
2 5
3 10
4 10 AUX / B, Buzzer relay (OPT, LAMP)
5 5
6 5
7 15
8 15
9 15
10 30
11 10
12 20
13 10
14 15
15 15
16 5
17 30, 20, 15, 10, 5
Slow-blow fuse
18
(60)
Slow-blow fuse
19
(60)
20 -
(F) Front
Protected circuit
Glow lamp
Starter relay
Radiator fan relay
Key stop timer
Meter (IGN)
Beacon / Fog lamp
Head light blinker (F)
Blinker (R) brake lamp
Radiator fan
DC output
---
Horn
Work light
Key stop timer
Meter (BAT)
Spare
Key switch
Alternator
Fuse puller
(20) Fuse puller
[RTV-X1120D]
Protected circuit
Fuse
Capacity (A)
No.
1 5
2 5
3 10
4 10 AUX / B, Buzzer relay (OPT, LAMP)
5 5
6 5
7 15
8 15
9 15
10 30
11 10
12 20
13 10
14 15
15 30
16 5
17 30, 20, 15, 10, 5
Slow-blow fuse
18
(60)
Slow-blow fuse
19
(60)
20 -
(A) Fuse
Protected circuit
Glow lamp
Starter relay
Radiator fan relay
Solenoid
Meter (IGN)
Beacon / Fog lamp
Head light blinker (F)
Blinker (R) brake lamp
Radiator fan
DC output
---
Horn
Work light
Solenoid
Meter (BAT)
Spare
Key switch
Alternator
Fuse puller
