Mechanical Installation

2.2
2.2 Mechanical Installation

Mounting Type Overview

Refer to the table below for a list of mounting types and necessary components.
Flush mounting – classic bricks
What You Need:
A precisely cut hole or, optionally, the brick
flush mounting box, Part No. 9151001
Flush mounting – thermally insulated wall
What You Need:
Longer screws (depending on the thermal
insulation thickness)
Flush mounting – hollow bricks
What You Need:
Brick flush mounting box, Part No. 9151001
