Product Overview

Read this manual carefully before using the product and follow the instructions
and recommendations included therein. Refer to wiki.2n.com for complete user
documentation.
2N IP Verso 2.0 is an elegant IP intercom equipped with a full HD camera, which
can be assembled exactly according to your needs thanks its modularity. It provides
a reliable access control and easy interoperability with other systems for a higher
building security. Thanks to SIP support and compatibility with major PBX and
phone manufacturers, it can benefit from using all VoIP networks. 2N IP Verso 2.0
can be used as a door or special purpose intercom for office buildings, residential
areas and other applications.

Installation Requirements

• LAN connection, UTP cable Cat5 or higher with an RJ-45 connector.
• PoE 802.3af or 12V DC ±10% / 3 A power supply.
• Completed installation of a surface mounting chassis or a flush mount
box for flush mounting.

Mechanical Installation

There are two ways how to install the device: flush mounting for classic brick
/ plasterboard walls or surface (wall) mounting.
• In each case, the main unit can be extended using the extending modules.
• The recommended installation height is 1350 mm from the ground till
the device camera level. The installation height may vary depending on
the device use.
!
• Before starting the mechanical installation on a selected place, make sure
carefully that the preparations associated with it (drilling, wall cutting) cannot
damage the electrical, gas, water and other existing wires and pipes.
• The warranty does not apply to the product defects and failures arisen as a result
of improper mounting (in contradiction herewith).The manufacturer is neither
liable for damage caused by theft within an area that is accessible after the
attached electric lock is switched on. The product is not designed as a burglar
protection device except when used in combination with a standard lock, which
has the security function.
• When the proper mounting instructions are not met, water might get in and
destroy the electronics. The intercom circuits are constantly under voltage
and water infiltration causes an electro-chemical reaction. The manufacturer's
warranty shall be void for products damaged in this way!
• Do not remove the plastic film on the seal inside the frame, otherwise water may
leak and damage the electronic components.
!
• Use the product for the purposes it was designed and manufactured for, in
compliance herewith.
• The manufacturer reserves the right to modify the product in order to improve
its qualities.
• 2N IP Verso 2.0 contains no environmentally harmful components. Dispose of the
device in accordance with the applicable legal regulations.

Electrical Installation

Description of terminals, connectors and available components:
