setupfru(8)
OPERANDS
EXTENDED
DESCRIPTION
EXAMPLES
EXIT STATUS
SEE ALSO
310 SPARC Enterprise Mx000 Servers XSCF Reference Manual • Last Revised November 2009
The following operands are supported:
device Specifies the device to be set up. Only the following device can be
specified:
sb
location Specifies the location of the device.
sb
In the M8000/M9000 server, the Quad-XSB configuration cannot be set in
■
memory mirror mode.
To set up an already mounted PSB again, all XSBs comprising the target PSB
■
must have been disconnected from the domain configuration and placed under
the system board pool. See the deleteboard(8) command for information on
how to disconnect XSBs from the domain configuration.
The configuration of the PSB varies according to the system as shown below.
■
In the M8000/M9000 servers, the PSB consists of one CPU/memory board
■
unit and one I/O unit in combination.
In the M4000/M5000 servers, the PSB consists of one CPU module and one
■
memory module logically divided into two on the motherboard unit, and one
I/O module.
Although a CMU with two CPUs can be configured into Quad-XSB mode on an
■
M8000/M9000 server, the server generates a "configuration error" message for
those XSBs that do not have a CPU and memory.
The current PSB settings can be checked by using the showfru(8) command.
■
Configures PSB#00 as a Quad-XSB (with memory in non-mirror mode be-
EXAMPLE 1
cause the memory mirror mode setting is omitted).
setupfru -x 4 sb 0
XSCF>
The following exit values are returned:
Successful completion.
0
An error occurred.
>0
addboard(8), deleteboard(8), moveboard(8), setdcl(8), showboards(8),
showdcl(8), showdevices(8), showfru(8)
Physical system board (PSB)
Integer from 0–15. Specify only one location.
