■ Individual call

Transmitting
Individual call allows you to make a call to a specific
station, and it provides private communication.
[Individual] key assignment is necessary to transmit
the Individual call.
▒ Not available on Non-display model.
1Push [Individual] to enter the Individual ID
selection mode.
• "INDV" inverts to "
• A pre-programmed ID name is displayed.
• When the ID name is not programmed, the ID
code is displayed.
• Push again to cancel and return to normal
operation. operation.
2Select the desired Individual ID (or name) using 2Select the desired Individual ID (or name) using
[CH Up]/[CH Down] or [CH Up/Down].
• The Individual ID can be edited with the 10-
keypad*. (Depending on the pre-set value.)
*10-key model only.
▒ To edit the Individual ID using the 10-keypad:
▒ Input the Individual ID directly with the 10-keypad.
▒ • Push [ ] to clear a code. ▒ P h [ ] t l
▒
▒
▒
▒
▒
▒
▒ ▒
3Push and hold [PTT] to transmit the Individual call
to the target station, then speak into the
microphone.
• The Busy/Transmit indicator lights red.
• Depending on the pre-set value, the target station
does not open the squelch, and communication is
not established, if the Individual ID or NAC not established, if the Individual ID or NAC
(Network Access Code) is not matched.
4Release [PTT] to receive.
APCO P25 Mode Operation
"
d
Receiving
1When an Individual call is received;
• The Busy/Transmit indicator lights green.
• The ringer sounds. (Depending on the pre-
setting.)
• The calling station ID (or name) is displayed for
2 sec. (Depending on the pre-set value.)
• Depending on the pre-set value, the transceiver
does not open the squelch, and communication is does not open the squelch, and communication is
not established, if the Individual ID or NAC
(Network Access Code) is not matched. Ask your
dealer for details.
2Push and hold [PTT] and speak into the
microphone.
3Release [PTT] to receive a response.
▒ For P25 Trunking mode operation:
▒ When the Full Off Air Call SetUp (FOACSU) function ▒ When the Full Off Air Call SetUp (FOACSU) function
▒ is turned ON, beeps sound after receiving a call. In
▒ that case, push [PTT] to accept the call. Then,
▒ operate as described in steps ② and ③ above. If
▒ you ignore the call by not pushing [PTT] for a
▒ specified time period*, communication is not
▒ established. Or, pushing [Home] after receiving the
▒ call will also ignore it. * Depending on the pre-set
▒ value ▒ value.

■ Talkgroup call

Transmitting
A Talkgroup call allows you to make a call to a
specific group only. [Talkgroup] key assignment is
necessary to transmit the Talkgroup call.
✔ For Trunking mode operation:
The [Talkgroup] key is not usable while in the
Trunking mode. To make a Talkgroup call, the group
affiliation should be performed with the desired
Talkgroup ID to call.
1Push [Talkgroup] to enter the Talkgroup ID (or
name) selection mode.
• "TGID" inverts to "
• A pre-programmed ID name is displayed.
• When the ID name is not programmed, the ID
code is displayed.
• Push again to cancel and return to normal
operation.
The calling station The calling station
name (or ID)
"
39
