Interface (Ports & Jacks)
Item Description

HDMI-Out Port

The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector
interface for transmitting uncompressed digital streams. This allows you to connect an external
monitor, TV or Flat Panel Display etc. as a display device (see "Attaching Other Displays" on
page C - 30) by means of a HDMI cable. Note that HDMI carries both audio and video
signals.

Headphone-Out Jack

Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.

Microphone-In Jack

Plug an external microphone in to this jack to record on your computer.
A

RJ-45 LAN Jack

This port supports LAN (Network) functions.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.

S/PDIF-Out Jack

This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-
capable PC to a Dolby AC-3 compatible receiver for "5.1" or 'dts' surround sound.

Security Lock Slot

To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be
purchased at any computer store.
Interface (Ports & Jacks) A - 3
