Interface (Ports & Jacks)
Item Description

Headphone-Out Jack

Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.

Line-In Jack

The Line-In jack allows you to play audio sources through the computer's speakers. Note that
audio input through Line-in will default to the mute setting. To set up your audio sources to play
through the Line-in jack go to the Sound control panel and make sure the Mute box is not
checked.
Microphone-In Jack Plug an external microphone in to this jack to record on your computer.
RJ-45 LAN Jack This port supports LAN (Network) functions.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
A

S/PDIF-Out Jack

This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-
capable PC to a Dolby AC-3 compatible receiver for "5.1" or 'dts' surround sound.

Security Lock Slot

To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be
purchased at any computer store.
Interface (Ports & Jacks) A - 3
