8W - 80 - 34
GREEN
2 1
CLUTCH INTERLOCK
SWITCH
BLACK
1
2
CLUTCH INTERLOCK
SWITCH JUMPER
BLACK
1
5 2
3
4
COMBINATION
FLASHER
J008W-7
8W-80 CONNECTOR PIN-OUTS
CAV CIRCUIT
1
F45 20YL/RD
1
T141 20YL
2 T141 20YL
2 F45 20YL/RD
CAV CIRCUIT
1 F45 18YL
2 F45 18YL
CAV CIRCUIT
1 L5 20BK
2 L9 20BK/PK
3 L12 20VT/TN
4 L6 20RD/WT
Z1 18BK
5
Z1 20BK
FUNCTION
FUSED B(+) ENGINE STARTER MOTOR RELAY
IGNITION SWITCH OUTPUT (START)
IGNITION SWITCH OUTPUT (START)
FUSED B(+) ENGINE STARTER MOTOR RELAY
FUNCTION
FUSED B(+) ENGINE STARTER MOTOR RELAY
FUSED B(+) ENGINE STARTER MOTOR RELAY
FUNCTION
FUSED IGNITION SWITCH OUTPUT (RUN)
FUSED B (+)
HAZARD FLASHER SELECT SIGNAL
FLASHER OUTPUT
GROUND
GROUND
RHD BUILT-UP-EXPORT
LHD DIESEL
EXCEPT LHD DIESEL
XJ
XJI08034
