Jeep 200 Cherokee Service Manual page 1049

8W - 90 - 2
DESCRIPTION AND OPERATION (Continued)
Connector Color
Name/Number
Blower Motor BK
Relay
Blower Motor BK
Resistor Block
Brake Lamp GY
Switch
Brake Warning BK
Pressure Switch
(LHD)
Brake Warning BK
Pressure Switch
(RHD)
C100 (LHD) BK
C100 (RHD) WT
C106 BK
C107 (2.5L) BK
C107 (4.0L) BK
C108 (Gas) BK
C109 BK
C111 (Diesel) LT GY
C112 (4.0L A/T GY
4WD)
C113 (Gas M/T)
C114 (Built-Up- BK
Export)
C115 (Built-Up- BK
Export)
C116 (Diesel) BK
C120 (Diesel) BK
8W - 90 CONNECTOR LOCATIONS
Location Fig.
Near T/O for N/S
C209
On HVAC N/S
Harness
Near Brake 21, 24,
Pedal 25
Left Side of 2, 10,
Engine 36
Compartment
Right Side of 5, 7,
Engine 13, 15,
Compartment 40
Left Lower 6, 14,
Instrument 21, 25
Panel
Right Lower 24, 40
Instrument
Panel
Left Front 1, 6, 7,
Engine 14, 15,
Compartment 38
Rear of Engine 2, 3, 4,
Compartment 5, 16
Rear of Engine 12, 13,
Compartment 17
Right Side of 4, 5, 6,
Engine 7, 12,
Compartment 13, 14,
15
Left Lower 14, 15,
Instrument 26, 27,
Panel 38
Left Rear of 36, 37,
Engine 42
Compartment
Left Side of 20
Transfer Case
Rear Center of 12, 17
Engine
Compartment
T/O at Left 1
Headlamp T/O
T/O at Right N/S
Headlamp T/O
Right Side of 39, 40,
Engine 41
Rear of Engine 36, 37,
41
Connector Color
Name/Number
C200 (LHD) GY
C201 (LHD) NAT
C202 (RHD) GY
C203 (RHD) BL
C204 (RHD) WT
C205 (LHD) YL
C205 (RHD) YL
C206 BK
C207 BK
C208 BK
C209 (LHD) BK/LT
GN
C209 (RHD) BK/LT
GN
C300 (LHD) NAT
C300 (RHD) WT
C301 WT
C303 NAT/
BK
(LHD)
WT
(RHD)
C304 BK
XJ
Location Fig.
Left Lower 21, 26
Instrument
Panel
Lower Center 21
of Instrument
Panel
Lower Center 24, 27
of Instrument
Panel
Lower Center 24, 27
of Instrument
Panel
Lower Center 24, 27
of Instrument
Panel
Left Lower 21, 22
Instrument
Panel
Right Lower 23, 24
Instrument
Panel
At Center 26, 27,
Console 32
Right Lower 21, 24
Instrument
Panel
Left Lower 21, 24
Instrument
Panel
Right Lower 32
Instrument
Panel
Left Lower 27
Instrument
Panel
At Right Kick 32
Panel
At Right Kick 24
Panel
At Right Kick 24, 32
Panel
T/O at Junction N/S
Block - C7 T/O
Right Lower B 29
Pillar
