LightSand S-2500B Installation And User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LightSand, Inc.
Installation and User Manual
for the
S-2500B Gateway
©LightSand, Inc.
279 Sinclair Frontage Road
Milpitas, California 95035
Part Number 004-10004-01
March 2004

Advertisement

Table of Contents
loading

Summary of Contents for LightSand S-2500B

  • Page 1 LightSand, Inc. Installation and User Manual for the S-2500B Gateway ©LightSand, Inc. 279 Sinclair Frontage Road Milpitas, California 95035 Part Number 004-10004-01 March 2004...

  • Page 3: Step 1: Log In To The Gateway

    Quick Start Guide The following guide will allow users who are familiar with the LightSand S-2500B Gateway to quickly set up a new system at a typical installation. The basic steps are: Log in to the gateway Define the SONET port...

  • Page 4: Step 2: Define The Sonet Port

    255.255.255.0. You can accept the default responses to the other prompts. If you want to rout IP traffic on the link, you must enable RIP on this port: gateway:> config tp pos 1 ip routing-protocol rip S-2500B Gateway...

  • Page 5: Step 4: Define The Local Interface

    If no 12000 or 3900 is present, BBCredit should be 7 throughout the fabric. If a 12000 or 3900 is in the fabric, BBCredit should be 4 throughout the fabric. Change the LightSand Gateway’s BBCredits for the appropriate FC port as follows: gateway:>...

  • Page 6: Step 7: Verify The Configuration

    The following optional commands can be used to show information about the gateway and verify the setup: gateway:> show sys all-info gateway:> show sys all-port gateway:> show sys all-tp gateway:> show port sonet 1 info gateway:> show tp pos 1 info S-2500B Gateway...
  • Page 7 gateway:> show tp pos 1 ip info (if IP enabled) gateway:> show tp pos 1 ip rip info (if IP enabled) gateway:> show port fc 1 info (if FC enabled) gateway:> show port ether 1 info (if IP enabled) gateway:> show port ether 1 ip info (if IP enabled) gateway:>...
  • Page 8 S-2500B Gateway...

  • Page 9: S-2500B Preface

    LightSand. LightSand will not have any liability for any damages arising from the use of the products in any high-risk activity, including, but not limited to, the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control, medical systems, life support or weapons systems.
  • Page 10 S-2500B Gateway...

  • Page 11: Table Of Contents

    Step 5: Verify the FC switches v Step 6: Configure SNMP agent vi Step 7: Verify the configuration vi S-2500B Preface vii Chapter 1: Introduction to the S-2500B Linking Your SAN via SONET 1-1 SONET 1-2 Fiber Channel Over SONET 1-2...
  • Page 12 Safety Precautions 4-1 Replacing Components 4-2 Access to the System Interior 4-2 Replacing the Power Supplies 4-4 Replacing a Cooling Fan 4-5 Replacing the Cooling Fan Bracket 4-7 Replacing a SCSI Hard Drive 4-8 Replacing the Battery 4-10 S-2500B Gateway...
  • Page 13 Table of Contents Appendix A: CLI Reference CLI Overview A-1 CLI Access Privileges A-1 Login A-1 Operational Commands A-3 Top Level Operational Commands A-7 Configuration Commands A-8 Configure the System A-9 Configure LGRP Data A-10 Configure SNMP Data A-10 Configure SNMP Trap Data A-11 Configure SNMP Community Strings A-12 Configure a Card A-13 Configure a Port A-14...
  • Page 14 Table of Contents Show Configuration A-32 Software Commands A-34 Appendix B: Redundancy S-2500B Gateway...

  • Page 15: Chapter 1: Introduction To The S-2500B

    Of the various choices of optical data transport, SONET offers a number of clear advantages for extending an FC-based SAN. The LightSand S-2500B Gateway has been optimized to make full use of these advantages for extending storage area networking.

  • Page 16: Sonet

    Credit buffering is a vital aspect of traffic control in a FC-based SAN. As distance (one component of latency) is added to the system, credit buffering becomes an even more crucial aspect of system design to guarantee that data is never dropped due to congestion. S-2500B Gateway...

  • Page 17: Ip Over Sonet

    TCP retransmission. In the critical area of buffer design, the S-2500B Gateway buffers are sized to store an amount of data equivalent to the need created if full latency is experienced over a full-rate link. Full rate transmission for the S-2500B can be sustained for up to 2000 km.

  • Page 18: Overview Of The S-2500B Gateway

    Overview of the S-2500B Gateway One S-2500B Gateway connects all of the FC switches in one SAN island to another SAN island. The physical interfaces are SONET (OC-48), Gigabit Ethernet (GbE) and/or Fibre Channel (FC). Each LightSand S-2500B Gateway is shipped with a set of control software pre- installed, including the CLI (Command Line Interface).

  • Page 19: Point To Point Topology

    IEEE 802.3z. Point to Point Topology Two S-2500B Gateways are directly connected via a SONET network in a point-to-point connection. This topology provides the highest performance, since the full bandwidth of the SONET link is dedicated to the Gateway SAN extension.

  • Page 21: Ports And Indicators

    CHAPTER 2 System Description Ports and Indicators The diagram below shows the ports and LED indicators on the back panel of the LightSand S-2500B Gateway. All optical ports use duplex connectors. FC / GbE Ethernet indicators Figure 2-1: S-2500B Back Panel...
  • Page 22 • One Serial port, which can connect to a computer or console for using the CLI. The LED indicators are described by the following label on the S-2500B back panel: Figure 2-2: S-2500B LED Configuration Label Alarm: amber means at least one alarm is present of critical or major severity; off •...

  • Page 23: Software Overview

    DB-9 serial cable (supplied with the system) from the serial port on the back panel of the S-2500B to the serial port of the console. The following settings should be used: baud rate 9600, no parity, 8 bits, 1 stop bit.

  • Page 24: Graphical User Interface

    Networking and Connections Overview The LightSand S-2500B Gateway has been designed to support connections with wide area, local area and storage area networks, and well as serial connection to a console. The following describes a typical configuration of the S-2500B Gateway’s ports: •...

  • Page 25: Lgrp Redundancy

    (called “nodes”) and for configuring each individual node. Refer to the SANman User Guide. Standard Connections The diagrams in this section show the S-2500B Gateway back panel and cable connections used in various standard configurations. System Description...

  • Page 26: Fc Connection

    FC Connection In the simplest configuration the S-2500B is connected through an FC port to a fibre channel switch, which in turn is connected to devices in a storage area network. The WAN port is used for a SONET connection to a remote gateway. The serial port supports direct communication with the gateway from a console.

  • Page 27: Fc And Gbe Connections

    FC and GbE Connections This configuration is similar to the FC connection described above, but adds a connection to a Gigabit Ethernet switch, which in turn connects to the LAN. Figure 2-4: S-2500B with GbE and FC Connections System Description...

  • Page 29: Chapter 3: System Configuration

    CHAPTER 3 System Configuration System Components The LightSand S-2500B Gateway shipment includes the following components: • The S-2500B Gateway • The S-2500B Installation and User Manual (this document) • The SANman Graphical User Interface software and the SANman User Guide •...

  • Page 30: Gateway Setup Procedure

    A Quick Start Guide has been included at the beginning of this manual for those familiar with the operation of the S-2500B Gateway. After a new S-2500B Gateway has been installed it must be assigned an IP address so that it can be accessed over the LAN. The assignment is made using the CLI (Command Line Interface) over a serial link.
  • Page 31 At the prompt (“gateway:>” or the gateway’s name, if it has already been configured), enter the command to display the current data for the system: gateway:> show system info Example response (note that the IP address is blank): Name gateway Description : LightSand Gateway IP Address Net Mask Type S-2500B Location Milpitas...

  • Page 32: Configuring The Ports

    Connect the gateway to the LAN by plugging an Ethernet cable into the LAN Ethernet port (labeled “1”) on the back panel of the S-2500B. To reboot the S-2500B with a “cold” restart, use the command: config system restart cold.

  • Page 33: Establishing A Point To Point Connection

    The only type of TP currently supported is Packet Over SONET (POS). The S-2500B Gateway supports only one POS TP on the SONET port. Create a channel (a point to point connection) between the new node and another gateway using the example below as a guide.

  • Page 34: Creating A Redundant Pair

    Creating a Redundant Pair To prevent loss of service due to equipment failure, two S-2500B Gateways can be linked as a redundant pair using the LightSand Gateway Redundancy Protocol (LGRP). For a complete discussion of LGRP redundant pairs, please refer to Appendix B: Redundancy.

  • Page 35: Configuration For In-Band Management

    Configuration for In-Band Management In-band management refers to controlling one S-155B from another through the WAN (SONET or SDH) link between the two gateways. In-band management requires IP traffic to be carried over the WAN link. This might be necessary when, for example, the remote gateway is not connected to the Internet for security reasons and therefore cannot be controlled from a workstation over the Internet.

  • Page 36: Running The Sanman Gui

    SANman User Guide. Monitoring and Performance LED Indicators There are seven LED indicators on the back panel of the S-2500B which can be used to monitor the system status. Figure 3-1 below shows the back panel label. The LED meanings are further described on the following page.

  • Page 37: Fault And Performance Monitoring Using The Gui

    • Alarm: amber means at least one alarm is present of critical or major severity; off means no significant alarms are present. • SONET Link/Act: on means the SONET link is enabled; off means disabled. • ON = FC, OFF = GbE: left to right for Ports 1, 2, 3. On means the port is configured for FC, off means it is configured for GbE.

  • Page 39: Chapter 4: Troubleshooting

    CHAPTER 4 Troubleshooting Your LightSand system is designed and tested to run trouble-free. If a problem does arise, use the procedures described below, and do not hesitate to contact LightSand for help. Contact information, including phone numbers, is available on our web site at www.lightsand.com.

  • Page 40: Replacing Components

    Replacing Components The procedures in this section require that you open the cover and work inside the system. Do not attempt to service the system except as instructed in this manual or in other LightSand documentation. CAUTION: Be certain to use proper ESD protection, including a wrist grounding strap, when performing the procedures in this section.
  • Page 41 Left door Right door Latch Security screw Figure 4-2: Opening the System Doors Press the latch on the system front panel and lift the left door. Lift the right door. Be sure to close the right door first and then the left door. Figure 4-3 shows the system cover bezel removed to provide an interior view of the system.

  • Page 42: Replacing The Power Supplies

    To install the replacement power supply, align the stud on the side of the power supply (see Figure 4-4) with the corresponding notch in the chassis, and then lower the power supply into the chassis. Slide the power supply toward the PDB until the power supply connector is fully seated in the PDB connector. S-2500B Gateway...

  • Page 43: Replacing A Cooling Fan

    Replacing a Cooling Fan There are six cooling fans in the system. Open the system doors. CAUTION: The cooling fans are hot-pluggable. To maintain proper cooling while the system is on, replace only one fan at a time. Locate the faulty fan. The amber fault indicator adjacent to the fan power connector blinks if the fan is faulty.
  • Page 44 Finger guard Power-supply cooling fan 1 System board cooling fans (4) Control panel board Power-supply cooling fan 2 Figure 4-5: Cooling Fan Replacement S-2500B Gateway...

  • Page 45: Replacing The Cooling Fan Bracket

    Replacing the Cooling Fan Bracket DANGER: The cooling fan bracket must be replaced only with the power turned off and the system disconnected from the electrical outlets. Open the system doors. Release tab Cooling fan bracket System board cooling fan connectors (4) Figure 4-6: Removing the Cooling Fan Bracket Remove the cooling fan bracket (see Figure...

  • Page 46: Replacing A Scsi Hard Drive

    The hard drives are “hot-swappable.” Open the drive carrier handle (see Figure 4-7) and wait until the drive spins down before proceeding. Slide the hard drive carrier forward until it is free of the drive bay Hard-drive carrier handle Figure 4-7: Replacing the SCSI Hard Drive and Carrier S-2500B Gateway...
  • Page 47 Installing a Replacement SCSI Hard Drive If your replacement hard drive is installed in its carrier, go to step 4. If the replacement hard drive has no carrier, remove the faulty hard drive from its carrier: Remove the four screws that secure the drive to the carrier (see Figure 4-8).

  • Page 48: Replacing The Battery

    You can pry the system battery out of its socket with your fingers or with a blunt, nonconducting object such as a plastic screwdriver. Install the new system battery with the side labeled “+” facing up (see Figure 4-9). 4-10 S-2500B Gateway...
  • Page 49 After 5 minutes connect the system to its electrical source and turn the power on. Log into the CLI and verify that the date and time are still correct. If not, call LightSand Product Support at (408) 941-2010, option 2.

  • Page 51: Appendix A: Cli Reference

    DB-9 serial cable (supplied with the system) from the serial port on the back panel of the S-2500B to the serial port of the console. The following settings should be used: baud rate 9600, no parity, 8 bits, 1 stop bit.
  • Page 52 From this point the prompts and available commands will depend upon the privileges assigned to the user’s account. • Operational Commands (page A-3) • Configuration Commands (page A-8) • Show Commands (page A-20) • Software Commands (page A-34) S-2500B Gateway...

  • Page 53: Operational Commands

    Operational Commands A user who logs in with the account name user or another account with normal privileges will see the following top-level prompt: gateway:> (or the previously configured gateway name) CLI operational commands are structured in levels. At each level a list of sub-context commands will move to the next lower level, while current-context commands will perform various functions and then stay at the same level or return to the next higher level.
  • Page 54 Figure A-1: Operational Command Tree S-2500B Gateway...
  • Page 55 CLI Reference...
  • Page 56 S-2500B Gateway...

  • Page 57: Top Level Operational Commands

    Top Level Operational Commands The following shows the top level prompt, the “?” request, and the list of valid commands: gateway:> ? Sub-Context: config show software Cur-Context: exit help logout quit ping <host-ipaddr> shutdown reboot For discussions of the sub-context commands, see the following: •...

  • Page 58: Configuration Commands

    Configuration Commands The CLI supports configuration of LightSand gateways (also called nodes or systems), and their cards, ports and termination points. (For adding nodes to the network, the GUI must be used instead of the CLI.) The following shows the level-specific prompt, the “?” request and the list of valid commands:...

  • Page 59: Configure The System

    Configure the System These commands are used for configuring data about the system (gateway) that is in communication with the current CLI session. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/config/system# Sub-Context: (none) Cur-Context: activate name <name>...

  • Page 60: Configure Lgrp Data

    The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/config/snmp# Sub-Context: trap community Cur-Context: (none) For discussions of the sub-context commands, see the following: • Configure SNMP Trap Data (page A-11) • Configure SNMP Community Strings (page A-12) A-10 S-2500B Gateway...

  • Page 61: Configure Snmp Trap Data

    Configure SNMP Trap Data These commands can be used to designate or undesignate the Manager’s IP address, to which SNMP traps should be sent. The port number should be specified as 162. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/config/snmp/trap# Sub-Context: (none) Cur-Context:...

  • Page 62: Configure Snmp Community Strings

    The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/config/snmp/community# Sub-Context: (none) Cur-Context: read <read-community> write <write-community> trap <trap-community> Example: Set the name of the community which can have read access to “public”: gateway/config/usr# read “public” A-12 S-2500B Gateway...

  • Page 63: Configure A Card

    Configure a Card For the current line of LightSand gateway products, only one card is supported, so no card number must be entered as part of these configuration commands. The following shows the level-specific prompt, the “?” request and the list of valid commands:...

  • Page 64: Configure A Port

    The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/config/port# ? Sub-Context: ether fc sonet efc wan Cur-Context: (none) The OC-48 card used in the S-2500B has the following ports: WAN 1 : a Wide Area Network port which can be configured to SONET protocol. • •...

  • Page 65: Configure A Termination Point

    (TP) on one gateway to a TP on another gateway in the network. The only type of TP currently supported is Packet Over SONET (POS). The S-2500B Gateway supports only one POS TP on the SONET port. The following shows the level-specific prompt, the “?”...
  • Page 66 To view the sub-context and current-context options at lower levels, use the “?” query for a specified TP. Example: View the commands available for the IP option: gateway/config/tp/pos/1# ip gateway/config/tp/pos/1/ip# ? Sub-Context: rip Cur-Context: ip-addr <ip-address> <net-mask> routing-protocol <routing-protocol> A-16 S-2500B Gateway...

  • Page 67: Configure System Level Ip Channel Data

    Configure System Level IP Channel Data These commands are used for configuring IP channel attributes at the system level. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/config/ip# Sub-Context: route Cur-Context: ttl-value <ttl-value> forwarding <forwarding>...

  • Page 68: Configure Ip Routing Table Data

    Example: Create an IP routing table entry for the interface with the given name, IP address and net mask. gateway/config/ip/route# create <InterfaceName> 10.0.0.1 255.255.255.0 For a list of valid interface names, refer to the routing information example in Show System Level IP Data, on page A-23. A-18 S-2500B Gateway...

  • Page 69: Configure Password

    Configure Password This command is used to change the password of the user who is currently logged in. Refer to the current-context commands in Configuration Commands (page A-8). CLI Reference A-19...

  • Page 70: Show Commands

    Show Termination Point Data (page A-28) • Show User Data (page A-29) • Show SNMP Data (page A-30) For discussions of some current-context commands, see the following: • Show Diagnostics (page A-31) • Show Configuration (page A-32) A-20 S-2500B Gateway...

  • Page 71: Show System Data

    Show System Data These commands display data about the system that is in communication with the current CLI session. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/system# ? Sub-Context: (none) Cur-Context: all-card all-port all-tp info...

  • Page 72: Show Lgrp Data

    Show LGRP Data (This section is under development.) A-22 S-2500B Gateway...

  • Page 73: Show System Level Ip Data

    Show System Level IP Data These commands display system level IP data and statistics. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/ip# ? Sub-Context: rip icmp Cur-Context: info stats all-routes Example: Display system level IP routing information: gateway/show/ip# all-routes For a discussion of sub-context commands, see the following: •...

  • Page 74: Show Ip Rip Data

    These commands display system level RIP data and statistics. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/ip/rip# Sub-Context: (none) Cur-Context: peer if-stats Example: Display RIP information and statistics for the peer gateway. gateway/show/ip/rip# peer A-24 S-2500B Gateway...

  • Page 75: Show Ip Icmp Data

    Show IP ICMP Data These commands display system level ICMP data and statistics. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/ip/icmp# Sub-Context: (none) Cur-Context: stats Example: Display ICMP statistics for the gateway. gateway/show/ip/icmp# stats CLI Reference A-25...

  • Page 76: Show Card Data

    Show Card Data These commands display descriptive and identification data about the S-2500B’s OC-48 card. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/card# ? Sub-Context: (none) Cur-Context: info all-info Example: Display a complete set of data about the OC-48 card:...

  • Page 77: Show Port Data

    Show Port Data These commands display data about a port of a particular type. The port’s type, for example SONET or FC, must be specified along with the port number. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/port# ? Sub-Context: ether fc sonet efc wan Cur-Context: (none)

  • Page 78: Show Termination Point Data

    Cur-Context: (none) Example: Select the POS 1 termination point and view the available commands: gateway/show/tp# pos 1 gateway/show/tp/pos/1# ? Sub-Context: (none) Cur-Context: info all-info Example: Display the distance, in milliseconds, between two gateways on the WAN. gateway/show/tp/pos/1# info A-28 S-2500B Gateway...

  • Page 79: Show User Data

    Show User Data This command displays a list of all users defined for the system and their access privilege level. The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/usr# ? Sub-Context: (none) Cur-Context: info Example: Display the list of users and access privilege levels: gateway/show/usr# info...

  • Page 80: Show Snmp Data

    The following shows the level-specific prompt, the “?” request and the list of valid commands: gateway/show/snmp# ? Sub-Context: trap community Cur-Context: (none) Example: Display information about the SNMP trap host machine: gateway/show/snmp# trap info Example: Display information about the SNMP read, write and trap communities: gateway/show/snmp# community info A-30 S-2500B Gateway...

  • Page 81: Show Diagnostics

    Show Diagnostics This command displays information for the system registers. Example: Display information for the system registers: gateway/show# diagnostics CLI Reference A-31...
  • Page 82 Show Configuration This command displays all system, FC, IP, LGRP, card and port configuration data. Example: gateway/show# cfg system.name:localhost system.description:SAN Extension Gateway system.location:End User Premise system.contact:Field Support system.ipAddr:10.1.1.164 system.netMask:255.255.255.0 system.eth0RipStatus:1 system.eth1RipStatus:1 system.state:1 system.restartMode:4 system.url: system.type:3 system.wwn:10:00:00:05:E3:01:00:26 system.swRelease:1.0.2 system.build:build_pre3_36_041703 fc.mrdSize:2112 fc.edtov:2 fc.ratov:10 ip.defaultGateway:10.1.1.1 ip.ttl:64...
  • Page 83 card.id:1 card.name:OPX Card card.description:OPX Card card.adminStatus:2 card.serialNo:13 card.mfgDate:11-08-2002 card.asmblyPartNo:200-00001-00 port.portId:1 port.type:1 port.name:OPX Port port.description:OPX Unconfigured Port port.loopbackTest:2 CLI Reference A-33...

  • Page 84: Software Commands

    Software Commands The software commands can be used to download a new software release, list information about the current software, or install a previous release. Contact your LightSand representative for information about obtaining new software releases. The following shows the level-specific prompt, the “?” request and the list of valid commands:...
  • Page 85 Appendix B: Redundancy This section is under development. Redundancy...
