Connecting the board for I/O operations

Connectors, cables – main I/O connector
The table below lists the board connectors, applicable cables, and compatible accessory products for the PCI-
DAS1602/16.
Connector type
Compatible cables
Compatible accessory
products with the
C100FF-x cable
The PCI-DAS1602/16 board's main I/O connector is a 100-pin high density connector labeled
pass through this connector. The pinout for eight-channel differential mode is shown on page 11. The pinout for
16-channel single ended mode is shown on page 12.
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections (available at www.mccdaq.com/signals/signals.pdf).
Caution! When connecting a cable to the board's I/O connector, make sure that the arrow indicating pin 1
on the board connector lines up with the arrow indicating pin 1 on the cable connector.
Connecting cables can damage the board and the I/O controller.
Board connector, cables, and accessory equipment
100-pin high-density Robinson-Nugent
C100FF-x
ISO-RACK16/P SCB-50
ISO-DA02/P SSR-RACK24 (DADP-5037 adaptor required)
BNC-16SE SSR-RACK08 (DADP-5037 with TN-MC78M05CT adaptor required)
BNC-16DI CIO-ERB24 (DADP-5037 adaptor required)
CIO-MINI50 CIO-ERB08 (DADP-5037 adaptor required)
CIO-TERM100 CIO-SERB08 (DADP-5037 adaptor required)
10
Installing the PCI-DAS1602/16
J1 . All signals
