PCI-CTR10 User's Guide
Connecting the board for I/O operations
Connectors, cables – main I/O connector
Table 2-1
lists the board connectors, applicable cables and compatible accessory boards.
Connector type
Compatible cables
Compatible accessory
products
Note 1: The BP-37/P is required to cable all CTR B signals from connector P2 to the PC bulkhead.
Pinout – main I/O connector
The PCI-CTR10 has two male, 37-pin D-type connector -
output and interrupt signals from the 9513 are all accessible on these connectors.
The signals on both connectors are identical. The second 9513 device on the PCI-CTR10 is accessible via
connector P2 at the rear of the board, and is wired identically to the 9513 device on connector P1.
PC +5V
DIN STROBE_A
DIN7_A
DIN6_A
DIN5_A
DIN4_A
DIN3_A
DIN2_A
DIN1_A
DIN0_A
OSC OUT_A
CTR5OUT_A
CTR4OUT_A
CTR3OUT_A
CTR2OUT_A
CTR1OUT_A
CTR1CLK_A
CTR1GATE_A
Table 2-1. Board connectors, cables, accessory equipment
! P1: 37-pin shielded, D-type, right angle
! P2: 37-pin unshielded, D-type, straight
C37FF-x, unshielded ribbon cable (Figure 2-2)
C37FFS-x, shielded round cable (Figure 2-3)
CIO-MINI37
CIO-MINI37-VERT
CIO-TERMINAL
SCB-37
BP-37/P (Note 1)
1
IRQ_A INPUT
20
IRQ_A ENABLE
2
21
3
DOUT7_A
22
DOUT6_A
4
23
5
DOUT5_A
24
6
D
OUT _A
4
25
7
D
OUT _A
3
26
8
D
OUT _A
2
27
9
D
OUT _A
1
28
10
D
OUT _A
0
29
11
GND
30
12
CTR5GATE _A
31
13
CTR5CLK _A
32
14
CTR4GATE _A
33
15
CTR4CLK _A
34
16
CTR3GATE _A
35
17
CTR3CLK _A
36
18
CTR2GATE _A
37
19
CTR2CLK _A
P1 (Counter A)
Figure 2-1. Board connectors P1 and P2
and
(see
Figure 2-1
P1
P2
PC +5V
20
DIN STROBE_B
21
DIN7_B
22
DIN6_B
23
DIN5_B
24
DIN4_B
25
DIN3_B
26
DIN2_B
27
DIN1_B
28
DIN0_B
29
OSC OUT_B
30
CTR5OUT_B
31
CTR4OUT_B
32
CTR3OUT_B
33
34
CTR2OUT_B
35
CTR1OUT_B
36
CTR1CLK_B
37
CTR1GATE_B
P2 (Counter B)
2-3
Installing the PCI-CTR10
.) Digital input, digital
1
IRQ_B INPUT
IRQ_B ENABLE
2
D
OUT
7_B
3
D
OUT _B
6
4
D
OUT _B
5
5
D
OUT _B
4
6
D
OUT _B
3
7
8
D
OUT _B
2
D
OUT _B
1
9
10
D
OUT _B
0
11
GND
12
CTR5GATE _B
CTR5CLK _B
13
14
CTR4GATE _B
CTR4CLK _B
15
CTR3GATE _B
16
CTR3CLK _B
17
18
CTR2GATE _B
CTR2CLK _B
19
