Chapter 2: Jumpers and Connectors
Backlight Connector(power)
Connector size: 1.25mm Wafer 2 Pin 90
Connector location: J10
J10
WAFER-M-90-1.25mm
J10
PIN
Definition
1
GND
2
Panel_backlight
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
O
2
1
Backlight Connector(data)
Connector size: 1mm Wafer 2Pin 90
Connector location: J8
J8
WAFER-M-90-1mm
J8
PIN
1
2
22
O
2
1
Definition
Brightness
BK_EN
VMC 1000 User Manual
