Chapter 1: Product Introduction
Mic-in Jack
Connector location: CN7
Connector size: EAR PHONE JACK PINK
Pin
Definition
1
FRONT_OUT_RC
LINE_OUTD
2
3
NC
4
FRONT_OUT_LC
5
ACON_GND
6
ACON_GND
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
Line-out Jack
Connector location: CN8
Connector size: EAR PHONE JACK GREEN
Pin
Definition
1
NC
MIC_JD
2
3
NC
4
MIC_OUT-L
5
ACON_GND
6
ACON_GND
14
VMC 1000 User Manual
