Chapter 2: Jumpers and Connectors

Touch Screen Connector

Connector size: FPC_1X4P-1mm
Connector location: CN1
CN1
1
1
2
2
3
3
4
4
MH1
MH1
MH2
MH2
FPC_1X4P-1mm
PIN Definition
1 TOUCH_XL
2 TOUCH_YD
3 TOUCH_XR
4 TOUCH_YU
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
Button & Sensor & LED Connector
Connector size: 1mm Wafer 10 Pin180
Connector location: J5
1
2
3
4
5
6
7
8
9
10
J5
WAFER-M-180-1mm
PIN
1
2
3
4
5
6
7
8 AUTO_BL_LED
9 POWER_LED
10
19
O
Definition
LS_D
LS_A
KEY_V+
KEY_V-
KEY_BL+
KEY_BL-
BOT_M_N
GND
