Chapter 1: Product Introduction
Getting to Know VMC 1000
Front View
1.Power On/Off Control
Press this button for 4 seconds -- the monitor will turn on.
2.Brightness Control
There are two modes for Brightness Control: Manual Mode
LCD brightness can be adjusted in 4 levels using the "+" or "-" buttons.
Auto Mode
The built-in light sensor will detect environmental brightness and adjust
LCD brightness automatically.
Switching between Manual Mode and Auto Mode
To toggle between Manual Mode and Auto Mode, press and hold the "+"
or "-" buttons for 4 seconds.
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
6
5
3
2
1
4
3.Volume Control
Audio volume can be adjusted in 8 levels using the buttons.
4.LED
PWR LED is turned on when VMD 1000 is powered on.
Mode LED is turned on when brightness control is in Auto Mode
5.Light Sensor
6.HSDPA Module Antenna Mounting Hole
7.WIFI Module Antenna Mounting Hole
7
7
VMC 1000 User Manual
