Appendix A: I/O Address Function
Delay On Time Setting
I/O port : 0EE7H
Bit7: Power On Delay
0: DISABLE(*)
1: ENABLE
Bit6: Power Off Delay
0: DISABLE(*)
1: ENABLE
Bit5~6
000
001
010
011
100
101
110
111
Delay Off Time Setting
Bit 2~0
000
001
010
011
100
101
110
111
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
Function Description
10 sec
30 sec
1 min
5 min
10 min
15 min
30 min
1 hour
Time (sec)
20 sec
1 min
5 min
10 min
30 min
1 hour
6 hour
18 hour
Startup and Shutdown Voltage Control
I/O port : 0EE8H
Only set by switch on motherboard(read only)
Bit3~2
11
01
10
00
When input voltage 12V
Bit1~0
00
01
10
11
33
Input Voltage
12V
24V
6~36V
6~36V
Input Voltage 12V
Startup Shutdown
11.5V 10.5V
Startup Shutdown
12V 11V
Startup Shutdown
12.5V 11V
Startup Shutdown
12.5V 11.5V
