SBC81206 PICMG 1.0 SBC User's Manual
1.1

Specifications

CPU
®
Intel Core
processor in the LGA775 Land Grid Array package
and Pentium
package)
System Chipset
®
Intel 945GC & ICH7/7R(Optional)
CPU Socket
LGA775
Front-Side Bus
533/800 MT/s (133/200 MHz)
BIOS
Phoenix-Award BIOS, Y2K compliant
8Mbit FWH Flash, DMI, Plug and Play
"Load Optimized Default" to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory
Two 240-pin unbuffered DDR2 DIMM sockets
Maximum to 2GB DDR2 400/533/667 MHz memory
Onboard Multi I/O
Controller: Winbond W83627HG
Parallel Port: one bi-directional with ECP/EPP/SPP support
Serial Ports: One ports for RS-232(COM1) and one port for
RS-232/422/485(COM2)
Floppy controller: supports two drives (1.44MB for each)
USB Interface
Six USB ports with fuse protection and complies with USB
Spec. Rev. 2.0
Display
Chipset Integrated VGA Controller and Supports up to
2048x1536 at 75 Hz resolution on non-interlaced CRT
2
®
TM
2 Duo, Celeron 400 series , Pentium
®
D processor (supports 775-Land
®
4
Introduction
