IDE Channel 0/1 Master/Slave
These items identify the types of each IDE channel installed in the
computer. There are 45 predefined types (Type 1 to Type 45) and
2 user's definable types (Type User) for Enhanced IDE BIOS.
Press <PgUp>/<+> or <PgDn>/<−> to select a numbered hard disk
type, or directly type the number and press <Enter>. Please be
noted your drive's specifications must match the drive table. The
hard disk will not work properly if you enter improper information. If
your hard disk drive type does not match or is not listed, you can
use Type User to manually define your own drive type.
If selecting Type User, you will be asked to enter related
information in the following items. Directly key in the information
and press <Enter>. This information should be provided in the
documentation from your hard disk vendor or the system
manufacturer.
If the HDD interface controller supports ESDI, select "Type 1".
If the HDD interface controller supports SCSI, select "None".
If the HDD interface controller supports CD-ROM, select "None".
CYLS. number of cylinders LANDZONE
HEADS number of heads
write precom
PRECOMP
If there is no hard disk drive installed, select NONE and press
<Enter>.
Drive A
Select the type of floppy drive installed in your system, and the
default is "None".
Halt On
This item determines whether the system will halt or not, if an error
is detected while powering up.
No errors The system booting will halt on any errors detected.
(default)
All errors Whenever BIOS detects a non-fatal error, the
system will stop and you will be prompted.
All, But The system booting will not stop for a keyboard
Keyboard
error; it will stop for other errors.
All, But The system booting will not stop for a disk error; it
Diskette will stop for other errors.
Phoenix-Award BIOS Utility
SBC81206 PICMG 1.0 SBC User's Manual
landing zone
SECTORS number of sectors
HDD access mode
MODE
