monitors via 15-pin D-Sub connector on the edge
Watchdog Timer
1~255 seconds; up to 255 levels
Ethernet
The LAN1/LAN2: Dual port with RTL8111B for Gigabit/Fast
Ethernet
Via PCI Express x1 bus
Wake-on-LAN support
Serial ATA
Built-in four SATA/SATA II ports onboard support the
maximum transfer rate up to 3.0 Gb/sec and SATA RAID
0/1/5/10 by ICH7R
Hardware Monitoring
Monitoring temperatures, voltages, and cooling fan status
Dimensions: 338 x 122 mm (6 layers)
NOTE All specifications and images are subject to change
without notice.
Introduction
SBC81206 PICMG 1.0 SBC User's Manual
3
