SBC81206 PICMG 1.0 SBC User's Manual
Current SYSTEM FAN1 Speed
Show you the current system fan1 speed.
Current SYSTEM FAN2 Speed
Show you the current system fan2 speed.
Vcore +3.3V/+5V/+12V/VBAT(V)/5VSB
It shows the voltage of +3.3V/+5V/+12V.
Press <Esc> to return to the Main Menu page.
5.12

Frequency/Voltage Control

This section is to control the CPU frequency and Supply Voltage,
DIMM OverVoltage and AGP voltage.
Auto Detect PCI Clk
The enabled item can automatically disable the clock source for a
PCI slot without a module, to reduce EMI (ElectroMagnetic
Interference).
Spread Spectrum
If spread spectrum is enabled, EMI (ElectroMagnetic Interference)
generated by the system can be significantly reduced.
56
Phoenix-Award BIOS Utility
