Removing The Cpu - EUROCOM M220S Service Manual

Disassembly

Removing the CPU

Figure 2 - 5
Processor
1. Turn the computer OFF, remove the battery
Removal
2. Remove the four screws from the heat sink
Sequence
Remove the four
screws from the
heat sink in the or-
der indicated.
5. Heat Sink
• 4 Screws
2 - 10 Removing the CPU
6
Desktop CPU Model
Reassembly Screw
Order
When replacing the
heat sink, make sure
you insert the screws
in the same order indi-
Figure 2 -
cated in
5
.
(page 2 - 6) and keyboard (page 2 -
in order - as indicated
5 1 4
4
1
7
2
3
5
6
5
Mobile CPU Model
8).
(Figure 2 - 5).
Caution
The heat sink, and
CPU area in general,
contains parts which
are subject to high
temperatures. Allow
the area time to cool
before removing these
parts.
4
1
2
3
