Removing The Cpu - EUROCOM M22ES Service Manual

Disassembly

Removing the CPU

Figure 2 - 5
Processor
1. Turn the computer OFF, remove the battery
Removal
2. Remove the four screws from the heat sink
Sequence
3. Release the fan cable(s)
a. Remove the four
screws from the
heat sink in the or-
a.
der indicated.
b. Release the fan ca-
bles.
Note: The heat sink for
the Mobile CPU is
thicker than the heat
sink for the Desktop
Figure
CPU (see
2 - 5
b).
5. Heat Sink
• 4 Screws
2 - 10 Removing the CPU
All manuals and user guides at all-guides.com
& accordingly and remove the heat sink.
6 7
6
b.
Reassembly Screw
Order
When replacing the
heat sink, make sure
you insert the screws
in the same order indi-
Figure 2 -
cated in
5
a.
(page 2 - 6) and keyboard (page 2 -
in order - as indicated (Figure 2 -
5 1 4
4
1
7
2
3
5
5
8).
5a).
Caution
The heat sink, and
CPU area in general,
contains parts which
are subject to high
temperatures. Allow
the area time to cool
before removing these
parts.
Desktop CPU Model
Mobile CPU Model
