Wireless LAN
VLAN Tag
Note: Leave one VLAN untagged at least to prevent from not connecting to Vigor router
due to unexpected error.
To add or remove a VLAN, please refer to the following example.
1. If, VLAN 0 is consisted of hosts linked to P1 and P2 and VLAN 1 is consisted of hosts
linked to P3 and P4. VLAN0 and VLAN1 are configured with different subnets.
Vigor2912 Series User's Guide
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
Enable – Check the box to enable the function of VLAN
with tag.
The router will add specific VLAN number to all packets
on the LAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by LAN.
VID – Type the value as the VLAN ID number. The range
is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
