WAN Connection
Detection
MTU
PPP/MP Setup
IP Address Assignment
Method (IPCP)
characters.
Password – Type in the password provided by ISP in this
field.
The maximum length of the password you can set is 62
characters.
Index (1-15) in Schedule Setup - You can type in four sets
of time schedule for your request. All the schedules can be
set previously in Application >> Schedule web page and
you can use the number that you have set in that web page.
Such function allows you to verify whether network
connection is alive or not through ARP Detect or Ping
Detect.
Mode – Choose ARP Detect or Ping Detect for the system
to execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you
have to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference.
TTL value is set by telnet command.
It means Max Transmit Unit for packet. The default setting
is 1492.
PPP Authentication – Select PAP only or PAP or CHAP
for PPP.
Idle Timeout – Set the timeout for breaking down the
Internet after passing through the time without any action.
Usually ISP dynamically assigns IP address to you each
time you connect to it and request. In some case, your ISP
provides service to always assign you the same IP address
whenever you request. In this case, you can fill in this IP
address in the Fixed IP field. Please contact your ISP before
you want to use this function.
WAN IP Alias - If you have multiple public IP addresses
and would like to utilize them on the WAN interface, please
use WAN IP Alias. You can set up to 8 public IP addresses
other than the current one you are using. Type the
additional WAN IP address and check the Enable box. Then
click OK to exit the dialog.
