Draytek Vigor2912 Series User Manual page 141

Item
RADVD Configuration
DHCPv6 Server
Configuration
DNS Server IPv6 Address
Static IPv6 Address
configuration
Current IPv6 Address
Table
When you finish the configuration, please click OK to save and exit this page.
Description
Enable – Click it to enable RADVD server. The router
advertisement daemon (radvd) sends Router Advertisement
messages, specified by RFC 2461, to a local Ethernet LAN
periodically and when requested by a node sending a Router
Solicitation message. These messages are required for IPv6
stateless auto-configuration.
Disable – Click it to disable RADVD server.
Advertisement Lifetime - The lifetime associated with the
default router in units of seconds. It's used to control the
lifetime of the prefix. The maximum value corresponds to
18.2 hours. A lifetime of 0 indicates that the router is not a
default router and should not appear on the default router
list.
Enable Server –Click it to enable DHCPv6 server.
DHCPv6 Server could assign IPv6 address to PC according
to the Start/End IPv6 address configuration.
Disable Server –Click it to disable DHCPv6 server.
Start IPv6 Address / End IPv6 Address –Type the start
and end address for IPv6 server.
Primary DNS Sever – Type the IPv6 address for Primary
DNS server.
Secondary DNS Server –Type another IPv6 address for
DNS server if required.
IPv6 Address –Type static IPv6 address for LAN.
Prefix Length – Type the fixed value for prefix length.
Add – Click it to add a new entry.
Delete – Click it to remove an existed entry.
Display current used IPv6 addresses.
131 Vigor2912 Series User's Guide
