About this Manual

Operation Manual
The Operation Manual gives all information about the normal operation and behavior of
the device. It is written for people who only operate the device and do not perform setup
and adjustment procedures. All device elements and software functions are described in
detail, although some of them might never be used. This manual does not cover any
application software. Refer to the appropriate application software manual to learn about
the application software.
Setup and Assembly Manual
The Setup and Assembly Manual is written for technical staff with some basic
mechanical as well as software skills. Many resellers will offer on-site installation;
therefore, large parts or all of the setup and assembly manual might not be of interest to
the reader. The access level at which the setup and adjustment processes are performed
is called "Power user". This "Power user" level is password protected from access by the
normal operator.
All available manuals for this device can be downloaded from our customer service portal
at http://portal.imageaccess.de. Be sure to always check for the latest versions of these
manuals.
This manual is divided into the sections A to E.
Section A describes the hardware of the device and gives an overview of all
components and connectors of the scanner. Remember that this device is a
precise optical instrument and should be handled accordingly.
Note: For the WideTEK 36 DS an appropriate floor stand is available. It is
recommended to always use the WideTEK 36 DS in combination with the
floor stand.
Section B describes the functions of the touchscreen and how to operate the scanner
with the touchscreen.
Section C describes the functions of the integrated Scan2Net interface.
Section D describes test and troubleshooting procedures.
Section E contains all technical data of the scanner and the manufacturer
declarations concerning safety and electromagnetic compatibility (EMC).
Manual Page 5
