B.4.2.2.4 Stitching
Select the stitching method, which is used to merge the image data to one image.
Fixed: Merges the image data at a specified offset area, resulting from the camera
calibration.
Adapt.1D: Recommended for all documents with good paper quality and plain surface.
It results in high throughput with large-sized documents.
Adapt.2D: Default setting, recommended for all documents with crumpled and uneven
surface. Merge the image data of the cameras dynamically. Reduce the
throughput but improves the results with problematic documents.
B.4.2.2.5 ICC Profile
ICC profiles add color correction values to each scanned image.
Chapter B.1.1 gives information about the buttons
Chapter A.10.3 gives information concerning the help function, which is activated by the
Question Mark symbol.
