General
Product overview - the ekey home system
5.
For a complete operational ekey home system you will need the following components:
Not all parts are supplied by ekey!
ekey home finger scanner
ekey home control panel
Power supply
Motor lock / Electric strike / Locking
system
optional
Cable transfer
ekey home is a biometric access system which is equipped with a finger scanner. This scanner reads
special features of your finger lines and uses them to recognise people with access rights. Each one of
your fingers has specific recognition features and also varies from the fingers of other people. ekey home
is available in different functional and mechanical versions and can therefore be optimally adapted to your
needs.
ekey home finger scanner versions
ekey home FS WM 2.0
ekey home FS IN 2.0
ekey home FS OM
© ekey biometric systems GmbH
ekey
FS OM
mounting
height varies
according to
finger scanner
model
floor
wall-mounted
1
integrable (door)
2
outlet-mounted
3
Operating instructions ekey home
min. 3 (depending on motor
locking system)
L
Supplied by Models
ekey
Yes
Yes
Yes
No
Yes
1
Description
on page
7
8
2 3
Page 6 / 41
